This class provides the interface between loaded MediaHandlers and call's audio/video streams. More...

#include <callservicesmanager.h>

Collaboration diagram for jami::CallServicesManager:

Public Member Functions
	CallServicesManager (PluginManager &pluginManager)
	Constructor registers MediaHandler API services to the PluginManager instance.

void	clearAVSubject (const std::string &callId)
	Clears all stream subjects related to the callId.

void	clearCallHandlerMaps (const std::string &callId)
	Removes call from mediaHandlerToggled_ mapping.

void	createAVSubject (const StreamData &data, AVSubjectSPtr subject)
	Stores a AV stream subject with StreamData properties.

std::map< std::string, std::string >	getCallMediaHandlerDetails (const std::string &mediaHandlerIdStr)
	Returns details Map from MediaHandler implementation.

std::vector< std::string >	getCallMediaHandlers ()
	List all MediaHandlers available.

std::vector< std::string >	getCallMediaHandlerStatus (const std::string &callId)
	Returns a list of active MediaHandlers for a given call.

	NON_COPYABLE (CallServicesManager)

bool	setPreference (const std::string &key, const std::string &value, const std::string &rootPath)
	Sets a preference that may be changed while MediaHandler is active.

void	toggleCallMediaHandler (const std::string &mediaHandlerId, const std::string &callId, const bool toggle)
	(De)Activates a given MediaHandler to a given call.

	~CallServicesManager ()

Detailed Description

This class provides the interface between loaded MediaHandlers and call's audio/video streams.

Besides it: (1) stores pointers to all loaded MediaHandlers; (2) stores pointers to available streams subjects, and; (3) lists MediaHandler state with respect to each call. In other words, for a given call, we store if a MediaHandler is active or not.

Definition at line 42 of file callservicesmanager.h.

Constructor & Destructor Documentation

◆ CallServicesManager()

jami::CallServicesManager::CallServicesManager ( PluginManager & pluginManager )

Constructor registers MediaHandler API services to the PluginManager instance.

These services will store MediaHandler pointers or clean them from the Plugin System once a plugin is loaded or unloaded.

Parameters

pluginManager

Definition at line 30 of file callservicesmanager.cpp.

References jami::emitSignal().

Here is the call graph for this function:

◆ ~CallServicesManager()

jami::CallServicesManager::~CallServicesManager ( )

Definition at line 35 of file callservicesmanager.cpp.

Member Function Documentation

◆ clearAVSubject()

void jami::CallServicesManager::clearAVSubject ( const std::string & callId )

Clears all stream subjects related to the callId.

Parameters

callId

Definition at line 84 of file callservicesmanager.cpp.

◆ clearCallHandlerMaps()

void jami::CallServicesManager::clearCallHandlerMaps ( const std::string & callId )

Removes call from mediaHandlerToggled_ mapping.

Parameters

callId

Definition at line 228 of file callservicesmanager.cpp.

◆ createAVSubject()

void jami::CallServicesManager::createAVSubject	(	const StreamData &	data,
		AVSubjectSPtr	subject
	)

Stores a AV stream subject with StreamData properties.

During the storage process, if a MediaHandler is supposed to be activated for the call to which the subject is related, the activation function is called.

Parameters

data
subject

Definition at line 43 of file callservicesmanager.cpp.

References DIR_SEPARATOR_CH, StreamData::direction, jami::emitSignal(), jami::PluginPreferencesUtils::getAlwaysPreference(), StreamData::id, StreamData::source, toggleCallMediaHandler(), and StreamData::type.

Here is the call graph for this function:

◆ getCallMediaHandlerDetails()

std::map< std::string, std::string > jami::CallServicesManager::getCallMediaHandlerDetails ( const std::string & mediaHandlerIdStr )

Returns details Map from MediaHandler implementation.

Parameters

mediaHandlerIdStr

Returns: Details map from the MediaHandler implementation

Definition at line 159 of file callservicesmanager.cpp.

References jami::emitSignal().

Here is the call graph for this function:

◆ getCallMediaHandlers()

std::vector< std::string > jami::CallServicesManager::getCallMediaHandlers ( )

List all MediaHandlers available.

Returns: Vector with stored MediaHandlers pointers.

Definition at line 136 of file callservicesmanager.cpp.

References jami::emitSignal().

Here is the call graph for this function:

◆ getCallMediaHandlerStatus()

std::vector< std::string > jami::CallServicesManager::getCallMediaHandlerStatus ( const std::string & callId )

Returns a list of active MediaHandlers for a given call.

Parameters

callId

Returns: Vector with active MediaHandler ids for a given call.

Definition at line 201 of file callservicesmanager.cpp.

References jami::emitSignal().

Here is the call graph for this function:

◆ NON_COPYABLE()

jami::CallServicesManager::NON_COPYABLE ( CallServicesManager )

◆ setPreference()

bool jami::CallServicesManager::setPreference	(	const std::string &	key,
		const std::string &	value,
		const std::string &	rootPath
	)

Sets a preference that may be changed while MediaHandler is active.

Parameters

key
value
rootPath

Returns: False if preference was changed.

Definition at line 213 of file callservicesmanager.cpp.

References jami::emitSignal().

Referenced by jami::JamiPluginManager::setPluginPreference().

Here is the call graph for this function:

◆ toggleCallMediaHandler()

void jami::CallServicesManager::toggleCallMediaHandler	(	const std::string &	mediaHandlerId,
		const std::string &	callId,
		const bool	toggle
	)

(De)Activates a given MediaHandler to a given call.

If the MediaHandler receives video frames from a hardware decoder, we need to restart the sender to unlink our encoder and decoder. When we deactivate a MediaHandler, we try to relink the encoder and decoder by restarting the sender.

Parameters

mediaHandlerId
callId
toggle	notify with new subjects if true, detach if false.

Definition at line 147 of file callservicesmanager.cpp.

References jami::emitSignal(), JAMI_ERR, and toggleCallMediaHandler().

Referenced by createAVSubject(), and toggleCallMediaHandler().

Here is the call graph for this function:

The documentation for this class was generated from the following files:
